Product Introduction
The FY390 Mini Skid Steer Loader is a powerful and versatile machine suitable for tight spaces and rough terrain. Its rugged engine provides high power output and low emissions, and its tires are made of high-quality rubber with excellent wear resistance, suitable for a variety of working conditions. The user-friendly console design makes it easy for operators to get started without complex training. Equipped with a variety of attachments, it is capable of moving heavy materials, digging ditches and clearing snow efficiently and accurately. The ergonomic and comfortable design ensures safety and comfort, while easy maintenance reduces downtime and increases productivity. A reliable investment for construction, landscaping or agricultural projects, the FY390 Mini Skid Steer Loader is suitable for a variety of tasks.
Product Details
Product Parameters
MODEL |
FY390 |
Gasoline Engine |
Briggs&Stratton, 13.5HP, EPA Certified |
Diesel Engine |
Koop, 14HP, Euro5 Certified |
No. of Cylinders |
1 |
No. of Pumps |
2 Pump Hydraulic System |
Displacement |
420cc |
Type |
Track/Wheel |
Overall Dimension (L*W*H) |
1450*800*1320mm (Wheel Version) 1500*900*1320mm (Track Version) |
Machine Weight |
900KG |
Operating Weight |
1200KG |
Rated Operating Capacity |
300KG |
Standard Bucket Capacity |
0.12m³ |
Max. Lift Force |
350KN |
Travel Speed |
0-6km/h |
Length with Standard Bucket |
2100mm |
Rollback of Bucket on Ground |
27° |
Max. Dump Height |
1510mm |
Height to Bottom of Level Bucket |
1810mm |
Height to Bucket Hinge Pin |
1870mm |
Max. Operating Height |
2450mm |
Overall Height |
1320mm |
Ground Clearance |
150mm |
Dump Reach |
450mm |
Dump Angle |
34° |
Rollback of Bucket at Full Height |
114° |
Wheelbase |
850mm |
Rear Axle to Bumper |
280mm |
Working System Pressure |
17-21MPa |
Fuel Tank Capacity |
5L |
Tread Width |
720mm |
Company Advantages
· The development of Fullwin Machinery mini skid steer loader for sale is considered from the perspective of green design.
· The product has gone through the stringent quality check under the supervision of qualified professionals to ensure premium quality.
· The possible flaws in production and on-time delivery of product quality and quantity are ensured in Qingdao Fullwin Machinery Co.,Ltd.
Company Features
· Qingdao Fullwin Machinery Co.,Ltd has been considered as an expert in the design and production of mini skid steer loader for sale. We have a strong production foundation and experience.
· Our teleological achievements are highly recognized by the industry.
· Qingdao Fullwin Machinery Co.,Ltd will adhere to the marketing of mini skid steer loader for sale style culture. Get more info!
Application of the Product
Fullwin Machinery's mini skid steer loader for sale is available in a wide range of applications.
Fullwin Machinery has a team of experienced professionals, mature technology and a sound service system. All this can provide customers with one-stop solutions.
